cnc wood woodworking machines/cnc router 4 axis/cnc wood working machines

The real 4 axis cnc picture show:

The Features of 4 axis cnc:

1) Whole machine is welded with seamless steel structure, which is high temperature annealing and

vibrating stress relief, so the lathe body is stabilized and will not be deformed forever.

2) Three axes adopt Taiwan brand linear guide rail with high precision.

3) Z axis adopts imported Taiwan made ball screw, so high precision and long life time using are assured.

4) X and Y axis is transmitted by helical rack and pinion. This makes the machine work faster and has larger cutting force compared with ball screw transmission.

5) Well compatibility: CAD/CAM designing software, such as type3/castmate/wentai/artcam, etc.

6) Manual/automatic oil-injection system allows the machine maintenance mush easier.

Technical Parameters of 4 axis cnc:

Working Area

1300*2500*200mm

Traveling Positioning Accuracy

±0.03/300mm

Repositioning Accuracy

±0.03mm

Table

T-slot Table

body

heavy duty frame body

Power of spindle

3.0kw water cooling spindle

X,Y,Z axis

Taiwan HIWIN Square rails

Max. Power Consumption

(Without Spindle) 2.5kw~3Kw

Max. Rapid Travel Rate

33000mm/min

Max. Working Speed

25000mm/min

Spindle and Power

air or water cooling spindle ,power optional

Spindle Speed

0-24000RPM

Drive Motors

stepper or servo motor

Working Voltage

AC380V/50/60Hz,3PH (Option: 220V)

Command Language

G Code

Operating System

Mach3 with USB

Computer Interface

USB

Flash Memory

128M(U Disk)

Collet

ER25

X,Y Resolution

<0.01mm

Software Compatibility

Type3/UcancameV9/Artcam Software and so on

Running Environment Temperature

0 – 45 Centigrade

Optional parts

1. air cooling spindle

2. Other control system:DSP, Syntec etc

3. vacuum table with vacuum pump

4.Servo motors (China or Japan brand)

5.Rotay: diamater 80mm,125mm,150mm,200mm,300mm

6.Dust collector

Samples picture show:

Our company:

Jinan AccTek Machinery Co., Ltd was located in high technology industry zone of Jinan,which specializes in manufacturing CNC and laser machines since 2005.

Our produces are wildely sold in many European and American countries. These products are very popular in these markets and have established a leading position in the carving machine field.

RFQ:

1) This is my first time to use this kind of AKM1325-3 cnc milling machine , is it easy to operate?

here are English manual and guide video showing how to use the cnc wood router.

If you still have difficulties operating the machine, we can solve your problems through phone or skype.

2) If there is something wrong with the machine after I ordered it, how could I do?

Free parts send to you during machine warranty period if machine went wrong.

Free after-sales service life for machine, please feel free to contact us if something is wrong with your machine.We offer 24 hours on line service each day, free technical support.

3) MOQ ?

Our MOQ is 1 set machine. We could send machine to the port of your country or your factory directly, please inform us your port or your detailed address.

After service:

1. one years quality guaranty, the machine with main parts(excluding the consumables)

shall be changed free of charge if there is any problem during the warranty period.

2. Lifetime maintenance free of charge.

3. Free training course at our plant.

4. We will provide the consumable parts at an agency price when you need replacement.

5. 24 hours on line service each day, free technical support.

6. Machine has been adjusted before delivery.

7. Our staff can be sent to your company to install or adjust if necessary.
